Topic: Shaper Duo

Socket Machining

Perfect fit for back spindle of Swiss Machines

Less Tool Pressure | Shorter Cycle Times

Traditional Methods of generating these features include:

End Milling - A small diameter endmill is driven by a high-speed spindle to create hexalobular (6-lobe) sockets. This method has some flexibility but,

Requires a high speed spindle | Involves complicated programs | Time consuming process

Shaper Duo: No need for high speed spindle | Simple program | Low cycle time

Conventional Broaching / Wobble Broaching - A sequence of form tools is pushed through a drilled hole until the desired socket size is formed. In most cases, dedicated broaching machines are purchased for high production parts. This equipment has a stroke length; a max distance they can travel. For a specific job the stroke would be defined by the broach length, the part material, and amount of material to be removed.

Need tool for each socket size | Hydraulic pressure build up pushes part effecting tolerances

Shaper Duo: Inserts can generate range of socket sizes | Low tool pressure | No special equipment needed | Consistant tolerances on parts

Low tool pressure is key for consistent part production

See the process in our Video

Square | Hexagon | Hexalobular (6-socket)

Reduce Cycle Time | Increase Production

Industries Serviced: Medical | Aerospace | Defense | Electronics | Automotive

Parts Include: Bone screws, medical devices, complex fasteners

Typical Materials: Titanium alloys (Ti-6Al-4v ELI), Stainless Steels (314), Brass, Aluminum, UHMWPE (ultra-high molecular weight polythylene), Nitinol, Magnesium alloys, Inconel

Case Studies

Product Brochure

Tooling Selection with EDP's
Process details
Programming code examples and tips (Citizen, Star, Tsugami)

Download

TIP of the MONTH

When implementing our Shaper Duo Tooling:

Use our Stick Duo Hyper sleeve It has an adjustable overhang mechanisim making indexing easier. (HY-NBH...)
Use our programming code examples and tips (in our catalog). Citizen | Star | Tsugami
